SEISMIC ANALYSIS OF EXISTING BUILDINGS

PSM has been providing seismic upgrade of existing buildings for over forty years. More recently, we have upgraded Essential Facilities with Enhanced Performance Objectives.

Several developments have greatly affected seismic upgrade design since we began in the 1970’s. Building codes and standards, driven by research and observation of damage from earthquakes, have specifically addressed existing building systems and historic construction materials, allowing structural engineers to analyze these components more rationally. This was accompanied by an increase in sophistication and usability of analysis software, greatly increasing the ability to review behavior of existing systems and upgrade options.

The other major change has been advances in understanding of regional seismicity throughout the country. When seismic design criteria was first introduced into Building Codes, the entire country had only 4 (later 5) Zones of seismic force level. Seismic analysis now relies on mircozonation, where seismic ground motions are determined by Zip Code.

SEISMIC UPGRADE OF EXISTING BUILDINGS

Seismic upgrade of existing facilities starts with information gathering, including client needs, available drawings and other information, material testing and analysis, and site reconnaissance. A formal seismic study is then performed, using ASCE 41. Seismic deficiencies are identified, and a path for further analysis is determined. Significant computer modeling of the existing structure is usually performed as part of this study.

Once these stages are complete, the selection and analysis of upgrade elements begins. In addition to iterative computer modeling of the selected schemes, coordination with other building elements, especially architectural and mechanical systems, is conducted. Finally, Construction Documents are completed.

Construction of a seismic upgrade project will require extensive structural engineering support, to address unforeseen field conditions, and alternates proposed by the contractor. An occupied building will present major challenges unless tenants are relocated during construction. PSM has extensive experience in seismic upgrade for occupied facilities. KIRO Television Broadcast House is an operating studio, which restricts noise and work hours. Magnuson Park Building 11, partially occupied during construction, included sensitive youth populations in therapy, and ongoing operations of recreation facilities.

HIGHER SEISMIC STANDARDS FOR ESSENTIAL FACILITIES

Building codes have long addressed the need for Essential Facilities to be designed to a higher seismic level than normal buildings, as they need to function after a major earthquake. More recently, ASCE 41 has given owners and their consultants specific tools to select Performance Levels above Life Safety. An Enhanced Performance Level for Essential Facilities will help to maintain the functioning of this type of facility after an earthquake.

Both Structural and Non-Structural Performance needs to be addressed for an Essential Facility, because of the need to remain operational. Non-structural seismic issues, including mechanical systems, ceilings, access floors, and other items, needs to be considered for an Essential Facility.

Latest Seismic Engineering Projects

Additional Seismic Engineering Projects

MAGNUSON PARK BUILDING 18 UPGRADE DESIGN

PSM provided final design for partial seismic upgrade and “temporary” restoration of the building envelope.

MAGNUSON PARK BUILDING 27 SEISMIC REVIEW

PSM provided a seismic and condition review of this 1920’s era airplane hangar, which was being considered for conversion to public uses.

PARK 90-5 POLICE FACILITY SEISMIC REPAIR AND UPGRADE

Seismic damage repair and upgrade for this Police facility.

DAKOTA STREET SUBSTATION SEISMIC UPGRADE

Seismic upgrade of this historic facility, which was converted from electrical distribution functions to community assembly use.

MAGNUSON PARK BUILDINGS 9, 26N AND 224 STRUCTURAL CONDITION REVIEW AND SCHEMATIC UPGRADE DESIGN

PSM provided the City of Seattle a rapid review and schematic upgrade design for these 3 historic buildings.

SEATTLE LIGHTING FIXTURE SEISMIC DAMAGE REPAIR

Immediately after the Nisqually Earthquake, PSM responded rapidly to re-open this facility to retail customers and office functions. After stabilizing the immediate hazards, we designed the repair for this heavily damaged structure, and worked closely over the next several months to restore the facility to full functionality.

DOWNTOWNER APARTMENTS SEISMIC DAMAGE REPAIR

PSM provided evaluation and repair services for the Downtowner Apartments, a nine-story, 80-year old concrete building, after the Nisqually Earthquake.

ARCTIC BUILDING SEISMIC STUDY

The City of Seattle commissioned us to study the adaptive reuse of this historic, 90 year old ten story building in Seattle’s downtown, including computer modeling and preliminary design of seismic upgrade schemes in using FEMA 356/ASCE 41.
